Pyrometer Blackbody Calibration Source

Pyrometer Blackbody Calibration Source

H-Series Pyrometer Blackbody Calibration Source has the characteristics of wide temperature range, large caliber, high stability, and can be set for cyclic temperature control.

It is designed in sections according to temperature, mainly used for calibration of radiation thermometer, infrared thermometer and radiation temperature sensor detector, and is widely used as a standard. It is not only suitable for the calibration of the measurement institutions and laboratories, but also can be used for the field calibration

Pyrometer Blackbody Calibration Source Advantage

  • Suitable for blackbody radiation sources between 50 ºC~1600 ºC
  • High emissivity
  • High stability
  • Cyclic temperature control

Pyrometer Blackbody Calibration Source Specification

Model

H600-D50

H600-D60

H1200-D50

H1600-D50

Temperature Range

(ºC)

50~600

100~600

50~1200

500~1600

Aperture(mm)

50

65

50

50

Emissivity

0.999

0.998

0.998

0.998

Stability(ºC)

0.1

0.1

0.1

0.1

Uniformity(ºC)

±(0. 15 and 0.15%t of the larger)

Temperature measuring hole

Controller Display Accuracy(ºC)

0.1

0.1

0.1

1

*Specifications and appearance are subject to change without prior notice.
