LED LightBar Measurement System

LED LightBar Measurement System

LED LightBar Measurement System adopts CIE127 standard to measure the light intensity, luminous flux and color of each LED on the front or side luminous LightBar.

The measurement results can be directly displayed by setting the determination range such as light intensity, color coordinates, color temperature, and wavelength.

Multiple lightbars can be measured simultaneously with a fixed interchanging fixture to improve test efficiency and achieve full production inspection requirements

LED LightBar Measurement System Specification

luminous flux(lm)

Measurement range

0.01~500 lm

light intensity(mcd)

Measurement range

10~50000 mcd

luminous flux/ light intensity& light source A

Accuracy

±3%

Repeatability

±1%

CIE 1931x,y@ light source A

Accuracy

±0.003

Repeatability

±0.0003

CS-4000 Spectrometer

wavelength range

380~780nm

Resolution

1nm

A/D

16bits

XY Platform

X effective travel

1200mm

Y effective travel

300mm

Z effective travel

100mm

Motion accuracy

±0.03mm/500mm

Power

Voltage range

150V Max 150V

Current range

1A Max 1A

Accuracy

0.01%+15mV

Accuracy

0.05%+0.1mA

Data output

Export to Excel


CS-4000 Spectrometer: CS-4000 high precision CCD spectrometer has been successfully applied in the fields of LED detection, color measurement as well as chemical analysis, LED light color parameters and spectral measurement, transmission, reflection, ambient light monitoring etc.
