VA-73/80 Fast Viewing Angle Analyzer

VA-73/80 Fast Viewing Angle Analyzer

VA-73/80 Fast Viewing Angle Analyzer is equipped with a high pixel resolution detector and a cone lens with different viewing angles. Viewing angle parameters such as luminance and chrominance of the screen at different angles can be obtained in one image, eliminating the cumbersome system measurement process. Cooperated with ProICM professional analysis software, it helps testers quickly customize product optimization solutions and improve product experience and productivity benefits.

VA-73/80 Fast Viewing Angle Analyzer Characteristic

  • VA-73 Fast Viewing Angle Analyzer is equipped with a 25 million pixel resolution detector and a ±73° large viewing angle conoscope lens.
  • VA-80 Fast Viewing Angle Analyzer is equipped with a 5 million pixel resolution detector and a ±80° large viewing angle conoscope lens.
  • All-round angle distribution of various displays and luminescent materials can be measured.
  • An optional filter wheel allows detection of a wide range of wavelengths.
  • Built-in image buffer memory and gigabit network interface enable high-speed measurement and data transmission.
  • The ProICM professional analysis software developed with dedication provides testers with the best software environment. It can automatic output test results to meet the needs of various in-depth analyses.

VA-73/80 Fast Viewing Angle Analyzer Application

  • LCD display
  • LCM module
  • optical materials
  • TV

VA-73/80 Fast Viewing Angle Analyzer Specification

Model

VA-73



Total Pixel

23.21million

Effective Pixels

5120*5120

Measurement Function

Radiation Intensity, Radiation Flux, Angular Distribution

Exposure Time

80us~10sec

Wavelength

500-1100nm

Filters

Single wavelength filter or multiple wavelength filters

Angle Resolution

0.039°

Measurement Diameter

4mm

Measurement Distance

3mm

Viewing Angle Range

±73°

Dimension

180*180*453mm(include lens)

Interface

LAN、Trigger

Operating Temperature

10~40°C

Input Voltage

AC  Adapter

*   Specifications and appearance are subject to change without prior notice.
