Glare Analyzer

Glare Analyzer

The GA-500M and GA-1200M glare analyzer is respectively equipped with 5 megapixel and 12 megapixel resolution detectors and 180 fisheye lens, effectively providing two indicators for CIE 117-1995:
1.UGR test is suitable for light sources with a stereo angle of 0.1~0.0003sr, so the resolution of the imaging photometer must be greater than 5 million pixels to ensure accurate measurement of 0.0003sr light source;
2.The maximum value of T/R in the Guth position index table is 3, so the FOV of the test system must be greater than 2×arctan3=143.14°.

The GA-2600 adopts Canon's 26-megapixel full-frame, high-resolution detector SLR camera, equipped with an 8mm fisheye lens or standard lens for indoor, outdoor, and road glare analysis.

Glare Analyzer Characteristic

  • Equipped with a Y filter that approximates human eye visual function.
  • The multiple exposure and ND filter can meet the wide measurement range, achieving up to 1000,000:1 contrast test.
  • Cooperated with professional glare analysis software, multi-point luminance data can be obtained in one photo, and the glare value can be calculated.
  • Support readout of ROI.

Glare Analyzer Application

  • Road
  • Tunnel
  • Indoor
  • Public stadium

Glare Analyzer Specification

Model

GA-500M

GA-1200M

GA-2600

Detector

2/3”

1.1”

\

Total Pixel

5 million

12 million

26 million

Pixel resolution

2448*2048

4096*3000

6240*4160

Pixel Size

3.45μm*3.45μm

3.45μm*3.45μm

\

Dynamic Range

>1000000:1(Multi Exposure)

>1000000:1(Multi Exposure)

\

Pixel Depth

12bits

12bits

\

Exposure Time

15μsec~10sec

15μsec~10sec

25μsec~30sec

Optional lens

8mm、16mm、25mm、50mm、Fisheye lens

8mm、16mm、25mm、50mm、Fisheye lens

Canon EFseries lends(Not included EF-S、EF-M)

Dimension

90*90*130mm

90*90*130mm

\

Interface接口

LAN or USB3.0

LAN or USB3.0

\

Operating Temp

5 to 50ºC

5 to 50ºC

0-40ºC

Measurement Function

Brightness, Glare

Brightness

Measurement Range0.001 to 100,000cd/m^2

Accuracy*¹±3%

Repeatability(σ)*¹±0.5%

Input Voltage

ACAdaptor
