SR-200 Spectroradiometer

SR-200 Spectroradiometer

SR-200 Spectroradiometer is equipped with eyepiece aiming window or built-in CCD camera to observe the image, integrating spectrum, luminance and chrominance measurement functions. The measurable parameters include: radiant luminance, luminance, relative spectral power distribution, chromaticity coordinates, correlated color temperature, color rendering index, etc., covering the light and color parameters of the measured object, which is extremely convenient for application measurement. It is widely used in the fields of FPD display, backlight source, lighting engineering, light source, light emitting devices, film and television, traffic signals, construction, atmospheric luminosity and so on.

SR-200 Spectroradiometer Characteristic

  • Equipped with eyepiece aiming window or built-in CCD camera.
  • High spectral resolution (up to 0.3NM/PIXEL) is achieved by matching array detectors with high-performance gratings.
  • It is integrated spectrum, luminance and chrominance measurement functions. The measurable parameters include: radiant luminance, luminance, relative spectral power distribution, chromaticity coordinates, correlated color temperature, color rendering index, etc.
  • The optional optical attenuator can achieve an ultra-wide range of 10E9 to meet the requirements of high contrast measurement.
  • Accurate measurement and analysis can be performed even at weak signals as low as 0.001cd/m^2 luminance.
  • The luminance and chrominance parameter are measured by spectrophotometry without spectral mismatching error, which can be used to calibrate the measuring equipment using the color filter method.

SR-200 Spectroradiometer Specification

Model

SR-200

Wavelength range

350nm~1000nm

Wavelength accuracy

±0.3nm

Observation window

Built-in CCD

Measurement Angle

1°;(Optional other angles)

Min Measurement distance

400mm

Max Measurement size

5.6mm

Measurement luminance range*1(under standard A light source)

0.005-100,000 cd/m2

Linear

±2%

Chromaticity accuracy (under standard A light source)

±0.0015x,y

Repeatability (under standard A light source)

Luminance:1%; Chromaticity:0.0005

Interface

LAN/USB

Power

AC adapter

Temperature/Humidity range

5 ~ 30℃,relative humidity less than 80% (no condensation)

Size (W*H*L)

240mm*150mm*160mm (Not include lens length)

*Measurement of luminance and chrominance measurement is based on RayClouds conditions (using 1000cd/m2standard light source,LED backlight, 6500K LCD display).
*Specifications and appearance are subject to change without prior notice.
