CM-10M Colorimeter

CM-10M Colorimeter

CM-10M Colorimeter is equipped with a highly sensitive sensor and four flexible interchangeable probes to meet the needs of close range measurement. The fine probe can accurately measure the luminance, illuminance, reflectance, transmittance and other optical performance parameters, and the measured data can be visually displayed on the LCD screen of the instrument interface within seconds.
The instrument is lightweight and supports mobile power supply, and it can measure the luminance and chrominance of target products such as mobile phone screens at any time when you go out. It can also be combined with simple test bracket to fix instruments to quickly test batch products, which is the preferred choice for multiple uses.

CM-10M Colorimeter Characteristic

● High Sensitive Colorimeter

* High Transmittance Filter

* High Sensitive Photo Diode

* Low Noise, High Sensitive Board Design

● High Speed and High Accuracy

* Iterative Precision:±0.5%(Lv),0.001(x,y)

* Accuracy:±3%(Lv),0.003(x,y)

* 16bits high speed sampling

● Wide Luminance Measurement Range:0.01~20000cd/m^2,fast measurement during radical change of Luminance through smart auto-gain Algorithm

● Flicker Measurement, support VESA、JEITA、FMA Mode

● Spectral tolerance of filter curve:≤±1%*λ

● OLED Display show measurement data directly or via USB/RS232 connect to PC.

● Flexible changeable probe can make it to finish luminance ,illuminance ,reflectance and transmittance measurement.

CM-10M Colorimeter Advantage

Dark(zero) Calibration
  • Measurement Dark(Zero) automatically
  • Imperviousness to temperature and humidity

Wide Iuminance Measurement Range
  • 0.01cd/m2~20,000cd/m2
  • fast measurement during radical change of Luminance through smart auto-gain Algorithm

Flicker Measurement
  • Accurate Measurement with High Frequency
  • Provide Flicker and Luminance Measurement

Spectral Characteristic
  • The filter response curves are based on the CIE1931 standard
  • Spectral tolerance of filter curve:≤±1%*λ
typical sensitivity


CM-10M Colorimeter Specification

Model

CM-10MSS

CM-10MS

CM-10M

CM-10MB

Detector

Silicon photo cell (CIE 1931 XYZ filter)

Measurement Diameter

Ø2mm

Ø4mm

Ø10mm

Ø23mm

Working

Distance

Within 10mm from the front of the lens

Integration time

1msec~5sec

A/D

16bit

Display Range

0.00001 to 100,000cd/m^2

Luminance Range

0.001 to 100,000cd/m^2

0.001 to 100,000cd/m^2

0.0001 to 50,000cd/m^2

0.0001 to 50,000cd/m^2

Accuracy*¹

0.01~5cd/m^2, ±3%

≥5cd/m^2 , ±2%

0.01~5cd/m^2, ±3%

≥5cd/m^2 , ±2%

0.01~5cd/m^2, ±3%

≥5cd/m^2 , ±2%

0.01~5cd/m^2, ±3%

≥5cd/m^2 , ±2%

Repeatability (σ)*¹

0.1~5cd/m^2 , 1%

≥5cd/m^2, 0.2%

0.1~5cd/m^2 , 1%

≥5cd/m^2, 0.2%

0.1~5cd/m^2 , 1%

≥5cd/m^2, 0.2%

0.1~5cd/m^2 , 1%

≥5cd/m^2, 0.2%

Color

Accuracy*¹

0.1~5cd/m^2, ±0.005

≥5cd/m^2, ±0.002

0.1~5cd/m^2, ±0.005

≥5cd/m^2, ±0.002

0.1~5cd/m^2,±0.005

≥5cd/m^2,±0.002

0.1~5cd/m^2, ±0.005

≥5cd/m^2, ±0.002

Accuracy (σ)*¹

0.1~5cd/m^2, 0.005

≥5cd/m^2, 0.0002

0.1~5cd/m^2, 0.005

≥5cd/m^2, 0.0002

0.1~5cd/m^2, 0.005

≥5cd/m^2, 0.0002

0.1~5cd/m^2, 0.005

≥5cd/m^2, 0.0002

Color

Temperature Accuracy

±200K

Flicker

FMA

Display Range:0~100%;Accuracy:±4%

JEITA

Measurement Range:≥10 cd/m^2, Frequency Range:0~256HZ, Accuracy:±0.5db

Measurement Speed

0.1~5cd/m^2

5sec

≥5cd/m^2

20/sec

Flicker

1024/sec,(JEITA or FMA)

Interface

USB2.0/RS232(or customized RS485)

Working

Temperature

5 to 50 ºC

Input Voltage

USB 5V

*Measurement of luminance and chrominance measurement is based on RayClouds conditions (using the standard LCD screen (6500K, 9300K)).

*Specifications and appearance are subject to change without prior notice.

CM-10M Colorimeter Ordering Details

Name

Category

Number

Probe

Ø2mm
Ø4mm
Ø10mm
Ø27mm

CM-P-2
CM-P-4
CM-P-10
CM-P-23

Data Cable

2m

3m

5m

10m

CM-USB-02

CM-USB-03

CM-USB-05

CM-USB-10

Power

5V-3A

CM-PW-05

CM Software

V1.0

CM-V1.0

Software Manual

CM Software

CM-SM-V1

Key

USB

CM-KEY-19

Calibration Certificate

Standard Light Source A

LED Light Source

Standard LCD at 6500K

CM-CAL-A

CM-CAL-LED

CM-CAL-LCD

Probe Mask(Optional)

Black Mask

CM-PM-01

Bracket(Optional)


Probe Bracket (Big)

Probe Bracket (Small)

CM-BL-01

CM-BS-02

Instrument Bag(Optional)


L*W*H (290*90*90mm)

CM-PK-041

*Note: Please order the appropriate product specifications according to your needs.
