Medium and Large-size Vertiacal BLU Optical Characteristic Measurement System

Cooperated with any brand of photometer, colorimeter or spectroradiometer for automatic luminance and chrominance and other optical parameter measurement.

It can provide accurate optical performance measurement data for the development of LCD, OLED and LED displays.

It is suitable for testing the optical characteristics of products such as laboratory research and development or production line quality inspection.

Contact

Overview
Characteristic
Tests Supported
Application
Specification

Medium and Large-size Vertiacal BLU Optical Characteristic Measurement System Overview

Multi-axis motion system and controller
Mechanical structure: vertical
Size: within 100 inches
Provide customized services

Medium and Large-size Vertiacal BLU Optical Characteristic Measurement System Characteristic

BL Test professional measurement software
Manual and automatic system control for initial positioning
Uniformity test of 5 points, 9 points, 13 points, 25 points, dot matrix test, plane test
Cooperated with signal generator to automatically provide a variety of signals
Excel data report
Automatic tracking algorithm of tested point
Site installation, commissioning and training
Free software upgrade
Supports simultaneous installation and switching of single or multiple instruments

Medium and Large-size Vertiacal BLU Optical Characteristic Measurement System Tests Supported

Luminance uniformity, luminance stability
Chrominance, color temperature, chrominance uniformity
Contrast, gamut coverage
Grayscale
GAMMA
Cross Talk
Response time
Warn Up Time
I-V-L of OLED

Medium and Large-size Vertiacal BLU Optical Characteristic Measurement System Application

Display backlight and module
Medium to large display in aviation military
TV backlight and module
Laptop backlight and module
Intelligent cockpit display

Medium and Large-size Vertiacal BLU Optical Characteristic Measurement System Specification

Model	DM-310	DM-320	DM-330	DM-340
Max Measurement Size	Diagonal30”(76cm)	Diagonal50”(127cm)	Diagonal70”(178cm)	Diagonal100”(254cm)
Connectable Luminance Meter	RayClouds：SR-880/880A/880H, SR-680/680A, C/FW/L/UA Series Topcon：BM-7AC,SR-5/5A/5AR, SR-UL1R/UL2 Konica Minolta：CS-200, CS-2000A, CS-3000 Photo Research：PR-655/670/680/680L, PR-880A
Measurement Items	Uniformity Test: 5points, 9points, 13points, 25points, Dot matrix test
Measurement Items	Color Gamut; Contrast; CIE Chromaticity; Color Temperature; Grey Level; Warm up Time; Luminance Stability; Response Time
PC Control System	Commercial PC, 19” LCD Monitor
XY Effective Travel	700mmX450mm	1200mmX700mm	1600mmX950mm	230mmX1300mm
Motion Accuracy	Straight line 0.04mm/500mm；Resolusion：±0.001mm
Z axis Effective Travel	200mm	300mm	550mm	1100mm
Image System	Industrial CCD and Industrial Lens, Video Collection Card
Software System	BackLightTest Professional version、Windows XP、7, Office
Dimension(WDH)	1.5m×1.0m×1.5m	1.7m×1.2m×1.7m	2.2m×1.5m×2.0m	2.6m×1.8m×2.3m
Power	220 VAC / 50 Hz
