Medium and Large-size Horizontal BLU Optical Characteristic Measurement System

Cooperated with any brand of photometer, colorimeter or spectroradiometer for automatic luminance and chrominance and other optical parameter measurement.

It can provide accurate optical performance measurement data for the development of LCD, OLED and LED displays.

It is suitable for testing the optical characteristics of products such as laboratory research and development or production line quality inspection.

Contact

Overview
Characteristic
Tests Supported
Application
Specification

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Overview

Multi-axis motion system and controller

Mechanical structure: horizontal

Size: within 80 inches

Provide customized services

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Characteristic

BL Test professional measurement software
Manual and automatic system control for initial positioning
Uniformity test of 5 points, 9 points, 13 points, 25 points, dot matrix test, plane test
Cooperated with signal generator to automatically provide a variety of signals
Excel data report
Automatic tracking algorithm of tested point
Site installation, commissioning and training
Free software upgrade

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Tests Supported

Luminance uniformity, luminance stability
Chrominance, color temperature, chrominance uniformity
Contrast, gamut coverage
Grayscale
GAMMA
Cross Talk
Response time
Warn Up Time
I-V-L of OLED

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Application

Display backlight and module
Medium to large display in aviation military
TV backlight and module
Laptop backlight and module
Intelligent cockpit display

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Specification

Model	DM-220	DM-230	DM-240
Max Measurement Size	Diagonal40”(102cm)	Diagonal60”(153cm)	Diagonal80”(203cm)
Connectable Luminance meter	RayClouds：SR-880/880A/880H, SR-680/680A, C/FW/L/UA Series Topcon：BM-7AC,SR-5/5A/5AR, SR-UL1R/UL2 Konica Minolta：CS-200, CS-2000A, CS-3000 Photo Research：PR-655/670/680/680L, PR-880A
Measurement Items	Luminance, Color Uniformity test: 5points, 9points, 13points, 25points; Dot matrix test
	Color Gamut; Contrast; CIE Chromaticity; Color Temperature; Grey Level; Warm up Time; Luminance Stability; Response Time
PC Control System	CommercialPC, 19” LCD Monitor
XY Effective travel	900mm X 550mm	1450mmX 900mm	1750mmX 1100mm
Motion Accuracy	Straight line 0.03mm/500mm；Resolution：0.001mm
Z axis effective travel	200mm
Image System	Industrial CCD and Industrial Lens, Video Collection Card
Software System	BackLightTest Professional version, Windows XP, 7, Office
Dimension(WDH)	1.5m×1.5m×1.8m	1.8m×1.8m×1.8m	2.2m×2.0m×2.0m
Power	220 VAC / 50 Hz

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Overview

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Characteristic

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Tests Supported

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Application

Medium and Large-size Horizontal BLU Optical Characteristic Measurement System Specification

Infrared Standard Radiation Thermometer
