CM-200 Luminance Colorimeter

CM-200 Luminance Colorimeter Characteristic

CM-200 Luminance Colorimeter has a portable exterior design, built-in lithium battery and power adapter, and can be used to measure various luminance conditions and non-contact luminance and chrominance measurement.
With wide luminance measurement range and optional illumination probe.
Circuit design with low noise and high sensitivity.
Equipped with XYZ filters close to the visual function of the human eye.
Various measurement modes are available to automatically select the most suitable measurement time.
The data is visually displayed on the external display.
Luminance is as low as 0.01cd/m2.
Target color can be set for chromatic aberration measurement.
Up to 20 user calibration channels.
Quickly obtain the chrominance of objects in the measured area without touching the sample and without being affected by the surrounding area.
Through the standard software, the instrument can be controlled for continuous interval measurement and custom measurement, and the software outputs the measurement data.

Model	CM-200
Detector	Silicon photocells (CIE XYZfilter)
MeasurementAngles	1º（or 0.2°）
MinimumMeasurementArea	5mm@1°；1mm@0.2°
FocusDistance	0.45m~infinity
MeasurementTime	AUTO：0.5～16sec. MANUAL：0.5～16 sec.
MeasurementFunction	Luminance,chrominance, color temperature, main wavelength, tristimulus value
Luminance	MeasurementRange	1°：0.01 to 1,500,000 cd/m2；0.2°：0.1 to 2,500,000 cd/m2
	Accuracy*¹	±2%@A light source
	Repeatability(σ)*¹	±0.2%@A light source
Chrominance	Based on standard Alightsource*¹	±0.002
	Based on LED lightsource*¹	±0.002
	Based on standardmonitor*¹	±0.002
	Other uncalibrated lightsources*¹	±0.01
	Repeatability(δ)*¹	±0.0003
Display	OLEDdisplay
UserCalibrationChannel	20
OperatingTemperature	5 to 50ºC
Dimension	60200150mm
CommunicationInterface	RS232C
PowerSupply	Built-inlithium battery and power adapter
